A.O. Smith >
Gold Xi Series 50-Gallon Commercial Electric Water Heater, 24 kW, 480V, 1-Phase, 6 Element, Indoor, Dual Magnesium Anodes, 2.63" Insulation
Description:
Gold Xi DVE displays detailed operational and diagnostic information. Fault or alert messages appear if an operational issue occurs. Last 9 fault and alert messages saved with time stamp. Control system automatically lowers the operating set point by a programmed value during user-defined time periods. Helps reduce operating costs during unoccupied or low demand periods. They can be used as recovery water heaters for hot water supply service or as boosters for supplying sanitizing rinse water for dish washing.
A. O. Smith offers the largest commercial product selection available, including the most specified commercial unit in the U.S. We offer more than 500 different commercial models, including gas fired, oil-fired and electric configurations, ranging in capacities from 5 to 10,000 gallons, with input range from 50,000 BTU to the equivalent of 4,000,000 BTU. Our comprehensive line is the natural fit for spec jobs requiring everything from the smallest commercial installation up to the largest multi-structure complex.
Additional Resources
Specification:
- Width (in):
- 21.75
- Weight (lb):
- 242
- Length (in):
- 21.75
- Height (in):
- 55.75
- Connection Size:
- 4-Mar
- Wattage:
- 24000
- Capacity (Gallons):
- 50
- Collection:
- Immersion Thermostat Gold XI
- Tank Warranty:
- 3 Years
- Parts Warranty:
- 1 Year
- Voltage:
- 480
- Product Type:
- Water Heater
- Diameter (in):
- 21.75
- Application:
- Commercial
- Thermal Efficiency:
- 98%
- Number of Elements:
- 6
- Country of Origin:
- United States
- Family Name:
- DVE-52
- Family Description:
- Gold Xi Series 50-Gallon Commercial Electric Water Heater
- Classification:
- Commercial Electric Tank
- All Type Of Item:
- Water Heater
- Installation Type:
- INDOOR
- Working Pressure (psi):
- 150
- Product Tier:
- GOLD-XI
- Rating Plate Model Number:
- DVE-52 100
- Rated Storage Volume:
- 46
- Anode Rod Type:
- Dual Magnesium Anodes
- Insulation Thickness (in):
- 2.63
- Power Source:
- Electric
- ASME Certified:
- No
- High Altitude Min:
- 0 FT
- High Altitude Max:
- 0 FT
- Side Loop:
- No
- Blanket Included:
- No
- Serial Number Required:
- Yes
- Hazmat:
- No
- Phase:
- 3-Jan
- Energy Star:
- No
