ProLine® 100-Gallon Ultra-Low NOx High Recovery Gas Water Heater, 98 Gallon, 75,100 BTU, Natural Gas, Indoor, Magnesium Anode, 1.88" Insulation
Description:
The ProLine® 100-Gallon Ultra-Low NOx High Recovery Gas Water Heater is designed to deliver reliable hot water for large demands. It includes a fully autmatic controls for more accurate temperature control and requires no electrical connections. For added peace of mind, this model includes a fixed automatic safety gas shutoff device.
Featuring a 98-gallon (nominal) tank and a 75,100 BTU gas burner, the GCN-100 standard vent delivers a thermal efficiency of 80%, a Uniform Energy Factor of 0.58, and a recovery rate of 81 gallons per hour. It carries a 6-year limited warranty, and meets Ultra-Low NOx emission requirements.
Environmentally-friendly insulation and factory-installed heat trap nipples reduce heat loss for maximum energy savings.
This ProLine® water heater is designed with A. O. Smith's superior commercial-grade tank protection. Advanced tank features include stainless steel CoreGard™ anode rod, Blue Diamond® glass lining and DynaClean™ automatic sediment-cleaning system, all designed to help protect the tank from the corrosive effects of water and extend the life of the water heater.
A. O. Smith’s ProLine® water heaters are residential products built to commercial-grade standards and are only available for purchase through professional wholesalers and contractors.
Additional Resources
Specification:
- Width (in):
- 27.75
- Weight (lb):
- 322
- Length (in):
- 27.75
- Height (in):
- 66.5
- Connection Size:
- 1/1/2004
- Capacity (Gallons):
- 98
- Collection:
- Ultra Low NOx High Recovery ProLine
- Tank Warranty:
- 6 Years
- Parts Warranty:
- 6 Years
- Product Type:
- Water Heater
- Diameter (in):
- 27.75
- Application:
- Residential
- Thermal Efficiency:
- 81%
- Fuel Type:
- Natural Gas
- Recovery GPH (90 degree F Rise):
- 82
- BTU/H on High:
- 75100
- Vent Size (in):
- 5
- Country of Origin:
- United States
- Venting Type:
- Atmospheric Vent
- Family Name:
- GCN-100
- Family Description:
- ProLine® 100-Gallon Ultra-Low NOx High Recovery Gas Water Heater
- Classification:
- Residential Gas Tank
- All Type Of Item:
- Water Heater
- Installation Type:
- INDOOR
- Working Pressure (psi):
- 150
- Product Tier:
- Proline
- Rating Plate Model Number:
- GCN-100 100
- Rated Storage Volume:
- 95
- First Hour Rating (gal.):
- 120
- Uniform Energy Factor (UEF):
- 0.58
- Ignition Type:
- Pilot with Piezo Igniter
- Anode Rod Type:
- Magnesium Anode
- Insulation Thickness (in):
- 1.88
- Height To Gas Valve (in):
- 16
- Power Source:
- Gas
- ASME Certified:
- No
- High Altitude Min:
- 0 FT
- High Altitude Max:
- 7700 FT
- ANSI Standard:
- CSA/ANSI Z21.10.3:19 - CSA 4.3
- Side Loop:
- No
- Blanket Included:
- No
- Serial Number Required:
- Yes
- Hazmat:
- No
- NOx Emissions:
- Ultra-Low NOx
- Energy Star:
- No
