Nibco >
S-585-70-66-HC 1/2 in. Two-Piece Bronze Ball Valve - Solder x Hose Connection
Description:
The NIBCO® bronze ball valve is equipped with reinforced PTFE seat ring and stainless steel stem and ball. The valve features solder and hose end connections along with a hose cap and chain.
The NIBCO® bronze ball valve provides ease of operation with quarter-turn (90 degrees) open to close and bubble-tight shutoff at 600 PSI. The two-piece valve is ideal for commercial and light industrial applications that require garden hose connections for drainage purposes. Please refer to NIBCO technical data sheet, valve selection guides and catalog for engineering and installation information. Choose NIBCO® ball valves for the most specified, versatile and economical valve option in commercial, mechanical and industrial applications. NIBCO® ball valves are backed by the NIBCO INC. 5-year 125% limited warranty.
- Valve pressure rating 600 psi 41.4 bar non-shock cold working pressure
- Maximum temperature rating 400°F
- Full port
- Blowout-proof stem
- Stainless steel ball and stem
- Solder end x 3/4" hose connection with cap and chain
- Standard lever handle
- Dezincification resistant
- Use in U.S. drinking water applications is prohibited after January 3, 2014
- Conforms to MSS SP-110
Additional Resources
Specification:
- Brand:
- Nibco
- Collection:
- S-585-70-66-HC
- Family Name:
- S-585-70-66-HC
- Family Description:
- Two-Piece Bronze Ball Valve - Solder x Hose Connection
- All Basic Material:
- Bronze
- All Type Of Item:
- Valve
- Size Dimensions:
- 1/2 in.
- Valve Gate Stem Design:
- Blowout-Proof
- Valve Pressure Rating (CWP):
- 600 psi
- Valve Ball Port Style:
- Full Port
- Valve Ball Material:
- Stainless Steel
